Rotary Lift Company History and Heritage — 100 Years of Innovation

The story of Rotary Lift begins in 1924 when Peter Lunati, a mechanic, conceived the idea of a hydraulic lift for automobiles after observing the mechanism of a barber shop chair. Working from that inspiration, Lunati built the world’s first automotive hydraulic lift. The design was patented on September 1, 1925, and the company Rotary was officially founded.

From that single invention, Rotary grew into the dominant force in the automotive lift industry. The company’s early hydraulic lifts were revolutionary — before Lunati’s invention, mechanics worked in pits dug into the shop floor or used primitive jack systems to access the underside of vehicles. The hydraulic lift transformed automotive service from a grueling, dangerous job into something that could be done efficiently and safely.

Throughout the decades, Rotary continued to innovate. They pioneered the asymmetric two-post lift design, which positions the vehicle slightly off-center between the columns to allow easier door opening — a design that is now standard across the industry. They developed the original “Double S” single-piece column, which became the benchmark for column strength and durability. They introduced direct-drive hydraulic cylinders that eliminated the need for chains in two-post lifts, reducing maintenance and improving reliability.

ATO7 — 7,700 lb Space-Saving Asymmetric Two-Post Lift

The ATO7 is designed for tight spaces. It requires the smallest minimum bay size in the Rotary lineup at just 11′ x 24′, and it is 14.5 inches narrower than the standard two-post lift. The asymmetrical column design allows easy entry from either side. This is the lift for shops with limited space that still need a quality two-post lift for Class 1 vehicle service.

• Capacity: 7,700 lbs
• Min. Bay Size: 11′ x 24′
• Configuration: Asymmetric
• Certification: ALI Gold Certified

SPOA7 — 7,000 lb Quick-Service Two-Post Lift

The SPOA7 is built for high-throughput quick-service operations. The adjustable, low-profile pads make vehicle spotting fast and accurate for routine maintenance and service. The optional Shockwave add-on provides faster rise speeds for operations where every second counts.

• Capacity: 7,000 lbs
• Configuration: Asymmetric with pad lift
• Optional: Shockwave fast-rise system
• Certification: ALI Gold Certified

SPO10 — 10,000 lb Symmetric Two-Post Lift

The SPO10 is the symmetric counterpart to the SPOA10, featuring wider drive-through lanes that give trucks and vans extra room. This lift is a versatile platform that can be configured with extended height options, thread-up or truck adapters, optional Shockwave, and Spotline assisted vehicle spotting.

• Capacity: 10,000 lbs
• Configuration: Symmetric
• Optional: Shockwave, Spotline, extended height
• Certification: ALI Gold Certified

SPOA10 — 10,000 lb Asymmetric Two-Post Lift (The Industry Standard)

The SPOA10 is the world’s best-selling asymmetric two-post lift. Period. It has held that title for over 30 years, and there is a reason: the combination of Rotary’s true asymmetric rotated column design, the original Double S single-piece column, direct-drive hydraulic cylinders, and the comprehensive safety system creates a lift that cannot be matched.

• Capacity: 10,000 lbs
• Overall Height: 11′ 8 1/2″
• Overall Floor Width: 11′ 5 3/8″
• Width Between Columns: 107 1/4″
• Drive-Thru: 95 1/4″
• Lifting Height: 72 3/4″ to 78 1/4″
• Low Pad Height: 4 3/4″
• Flip-Up Adapter Steps: 4 3/4″, 7″, 10 1/4″
• Column Steel Thickness: 1/4″
• Motor: 2 HP, 208-230V, 60Hz, single phase, 12-16 amps, 20A circuit
• Lifting Time: 48 seconds unloaded, 53 seconds at rated capacity
• Floor to Overhead Shut-Off: 11′ 2 3/4″
• Cylinder Height (Full Rise): 11′ 10 1/2″
• Min. Ceiling Height: 144″ (12′)
• Concrete Requirement: Minimum 4 1/4″ at 3,000 PSI
• Shipping Weight: 1,750 lbs
• Warranty: 5-year structural / 1-year parts and labor
• Certification: ALI Gold Certified, tested beyond 20,000 cycles
• Colors Available: Blue, Black, Red

Key features that set the SPOA10 apart from the competition:

• True Asymmetric Rotated Column Design: The columns are rotated 30 degrees, positioning the vehicle rearward so both doors clear the columns for easy technician entry and exit.
• Direct-Drive Hydraulic Cylinders: No chains to stretch, adjust, or replace. Direct-drive systems are lower maintenance and more reliable over the long term than chain-over-roller designs.
• Hydraulic Safety System: Automatic at all positions — no reliance on mechanical latches as the primary safety. The hydraulic system itself locks the lift in position.
• 2-Stage Arms with FA Flip-Up Adapters: Standard configuration provides versatility for various vehicle pickup points.
• Single-Point Lock Release: Unlock both columns from one side for faster operation.
• Self-Lubricating UHMW Polyethylene Slide Blocks: Reduce friction and maintenance compared to traditional slide bearings.
• Hydraulic Hoses Routed Inside Columns: Protected from damage and UV exposure.

SPOA10-AV — All-Vehicle Variant

The SPOA10-AV adds All-Vehicle (AV) lift arms designed to handle the widest range of vehicles, including battery electric vehicles and exotics. Standard equipment includes 4 adjustable truck adapters, 4 adjustable round adapters, 4 adapter extensions at 3 1/2″ height, and 4 adapter extensions at 5″ height. This is the configuration you want if your shop services everything from economy cars to EVs to lifted trucks.

SPO12 — 12,000 lb Symmetric Two-Post Lift

The SPO12 steps up to 12,000 lbs capacity for shops that handle medium-duty vehicles. This lift is three feet taller than standard two-posts, providing more clearance for tall cargo vans and a more comfortable, ergonomic working height for technicians. The SPO12 has the highest overall height in the industry for its capacity class.

• Capacity: 12,000 lbs
• Rise: 72 3/4″ to 75 1/4″ (standard); 75 3/4″ to 78 1/4″ (with Shockwave)
• Overall Width: 11′ 5 5/8″
• Drive-Thru Width: 8′ 6 3/8″
• Front/Rear Arm Min/Max: 27 1/2″ to 59″
• Min. Adapter Height: 4 3/4″
• Time of Full Rise/Descent: 60 sec / 40 sec (standard); 25 sec (Shockwave)
• Min. Bay Size: 12′ x 26′
• Overall Height: 13′ 8″ (standard)
• Required Ceiling Height: 14′
• Motor: 2 HP, 208V-230V
• Optional Shockwave: 5 HP motor, 110V, 25-second full rise
• Configuration: Symmetric with adjustable 3-stage arms, stackable thread-up truck adapters
• Warranty: 5-year structural / 1-year functional / 1-year labor
• Certification: ALI Gold Certified

SPO16 — 16,000 lb Heavy-Duty Two-Post Lift

The SPO16 brings serious heavy-duty capability to the two-post format. At 16,000 lbs, it handles Class 1-4 vehicles with ease. The SPO16-AV-LC (low-clearance) variant offers overall height options of 162″ or 174″, making it adaptable to various ceiling heights.

• Capacity: 16,000 lbs
• Configuration: Symmetric
• Arm Type: 3-Stage AV (All-Vehicle) Arms
• Min. Adapter Height: 4 3/4″
• Overall Height Options: 162″ or 174″ (LC variant)
• Optional: Shockwave
• Certification: ALI Gold Certified

SPO20 — 20,000 lb Super Heavy-Duty Two-Post Lift

The SPO20 is the heavyweight of the Rotary two-post lineup. At 20,000 lbs capacity, it handles vehicle classes 1 through 5 — everything from small cars to medium-duty trucks. This lift is a game-changer for fleet maintenance facilities that need a single lift platform capable of servicing their entire vehicle range.

• Capacity: 20,000 lbs
• Configuration: Symmetric
• Customizable Options: Shockwave, extended configurations
• Certification: ALI Gold Certified

SPO16 Detailed Specifications

The SPO16 fills a critical gap in the heavy-duty two-post market. At 16,000 lbs, it handles vehicle Classes 1-4 — everything from standard passenger cars to medium-duty delivery trucks and work vans. The 3-stage AV (All-Vehicle) arms provide the reach and flexibility needed for the wide range of vehicles in this capacity class.

• Capacity: 16,000 lbs
• Configuration: Symmetric
• Arm Type: 3-Stage AV (All-Vehicle) Arms
• Min. Adapter Height: 4 3/4″
• Overall Height Options: 162″ or 174″ (LC variant)
• Motor: 2 HP, 208-230V single phase
• Optional: Shockwave fast-rise system
• Certification: ALI Gold Certified
• Warranty: 5-year structural / 1-year functional / 1-year labor

The SPO16-AV-LC (low-clearance) variant is particularly useful for shops with lower ceiling heights that still need heavy-duty capacity. By offering overall height options of 162″ or 174″, Rotary makes 16,000 lbs of capacity accessible to facilities that cannot accommodate the taller standard-height heavy-duty lifts. This opens up heavy-duty service capability for shops that might otherwise be limited to 10,000-12,000 lb lifts due to ceiling constraints.

SPO20 — The Maximum Two-Post Capacity

The SPO20 at 20,000 lbs is the most capable two-post lift Rotary produces. It handles vehicle Classes 1-5, which covers virtually every vehicle from a compact car to a Class 5 medium-duty truck (up to 19,500 lbs GVW). For fleet maintenance facilities that need a single two-post platform capable of servicing their entire vehicle range, the SPO20 eliminates the need for multiple lifts at different capacity points.

• Capacity: 20,000 lbs
• Configuration: Symmetric
• Motor: Heavy-duty power unit
• Optional: Shockwave fast-rise, extended configurations
• Certification: ALI Gold Certified
• Warranty: 5-year structural / 1-year functional / 1-year labor

The SPO20 is particularly popular with mixed fleet maintenance operations — military bases, municipal vehicle shops, and corporate fleet facilities where the vehicle mix ranges from sedans to medium-duty trucks. Rather than outfitting the facility with different lifts for different vehicle types, a bay of SPO20 lifts handles everything.

Rotary Four-Post Lift Product Line — SM14 and SM18

Rotary’s four-post lifts are built with the same engineering philosophy as their two-post models: maximum strength, maximum reliability, and features that make daily operation efficient and safe. The SM14 and SM18 are the workhorses of the four-post lineup.

Inground Lifts

Rotary is the leading manufacturer of inground lifts. These lifts mount flush with the shop floor when not in use, providing a clean appearance and full drive-through capability. Inground lifts are standard equipment in many premium dealerships (BMW, Mercedes-Benz, Porsche, etc.) where the service department appearance matters as much as functionality.

SmartLift SL210 — 10,000 lb Inground Two-Post Lift

Since 1995, the Rotary SmartLift has been the number one choice for dealerships looking to increase their shop’s productivity and profitability. The SL210 is the standard 10,000 lb model, designed to maximize space, increase technician productivity, and lower total cost of ownership.

• Capacity: 10,000 lbs (per arm: 2,500 lbs)
• Rise: 75 7/8″ to 81 3/8″
• Width Overall: 108 1/4″
• Drive-Thru Clearance: 88″
• Arm Reach (min/max): 19 1/4″ to 41 1/4″
• Overall Arm Reach (min/max): 54 1/2″ to 99″
• Min. Adapter Height: 4 1/4″
• Guide Plunger Diameter: 8 1/2″
• Voltage: 208V-230V single phase
• Time of Full Rise/Descent: 53 sec / 24 sec (RA model); 57 sec / 29 sec (TA model)
• Min. Bay Size: 11′ x 24′
• Available Models: SL210-RA (round adapters), SL210-TA (truck adapters)
• Shockwave Option: Available — increases rise speed by 22%

Key SmartLift technologies include:

• Easy Access Cylinders: Patented design allows all routine maintenance at floor level without removing inground lift components. Without the need for forklifts or component removal, downtime is cut by 75% compared to traditional inground lifts.
• SmartGuard Coating: Proprietary coating applied to lift plungers and other select inground components to prevent corrosion and provide years of trouble-free use. Corrosion is the biggest enemy of inground lifts because the components are exposed to moisture and chemicals below floor level.
• Space Efficiency: For every 11 surface lifts, shops can now fit 12 SmartLifts. The flush-floor design eliminates the column footprint that surface-mounted lifts require, reclaiming floor space for additional lift bays or improved vehicle access.

The SmartLift is the preferred inground lift for premium dealerships — BMW, Mercedes-Benz, Porsche, Audi, and other luxury brands frequently specify Rotary SmartLift equipment for their service centers. The flush-floor aesthetic complements the premium environment these dealerships maintain, while the productivity features ensure technicians work efficiently.

SmartLift SL212 — 12,000 lb Inground Lift

The SL212 steps up to 12,000 lbs capacity for dealerships and shops that service heavier vehicles. Same SmartLift technology and features as the SL210 with the additional capacity needed for full-size trucks, large SUVs, and light commercial vehicles. Available with Shockwave option for faster cycle times.

MACH Series Mobile Column Lifts — MCHM14 and MCHM19

Rotary’s MACH Series mobile column lifts bring the quality and innovation expected from the Rotary brand to the heavy-duty portable lifting space. The MCHM14 and MCHM19 are wireless, remote-controlled mobile column systems designed for fleet maintenance, truck repair, bus depots, and heavy vehicle service.

MCHM14 — 14,000 lb Per Column Mobile Column Lift

• Capacity Per Column: 14,000 lbs
• Set of 2: 28,000 lbs total
• Set of 4: 56,000 lbs total
• Set of 6: 84,000 lbs total
• Rise: 69″ (1,760 mm)
• Column Width: 43″ (1,092 mm)
• Clearance/Fork to Column: 10″ (254 mm)
• Speed of Rise: 68 seconds
• Charging Voltage: 110V charger (2.5 amps max)
• Wheel Rim Size: 9″ to 24″
• Features: Wireless remote control, digital gauges for height/weight, LockLight technology, forklift pockets, spring-loaded steering/braking, rubber-coated steel wheels, inverted hydraulic cylinder rod
• Certification: ALI Gold Certified
• Warranty: 5-year structural / 1-year functional / 1-year labor

MCHM19 — 19,000 lb Per Column Mobile Column Lift

The MCHM19 steps up to 19,000 lbs per column for the heaviest commercial vehicles. A set of 4 provides 76,000 lbs total capacity, handling Class 8 trucks and heavy transit buses.

MACH Series Key Features

• Wireless Remote Control: Individual column controls provide flexible operation from anywhere around the vehicle. The remote allows the operator to maintain visual contact with all columns during lifting.
• Digital Gauges: Display vehicle height and weight on each column, providing real-time feedback during lifting operations.
• LockLight Technology: Visual indicator system for enhanced safety — provides clear feedback on lock status at each column position.
• Powered by Redfire: Rotary’s advanced power system for reliable battery operation.
• Inverted Hydraulic Cylinder Rod: Protects the cylinder rod from damage and contamination by keeping it inside the cylinder during storage and transport.

Scissor Lifts and Alignment Lifts

Rotary produces scissor lifts for alignment, general service, and quick lube applications. Their alignment lifts integrate with major alignment system manufacturers and include built-in turntables and slip plates. Rotary’s scissor lift lineup provides an alternative to four-post lifts for alignment applications, with the advantage of a lower profile when fully lowered.

Rotary Technology and Innovation — Shockwave, Spotline, and Direct Drive

Rotary’s 100-year history of innovation continues with proprietary technologies that no other manufacturer offers.

Made in the USA

Rotary lifts sold in North America are manufactured in Madison, Indiana. For shops that want American-made equipment — whether for personal preference, Buy American compliance, or government contract requirements — Rotary delivers. This is not assembled in America from imported components. This is designed, engineered, fabricated, and assembled in Indiana.

The Parts and Support Ecosystem

VSG/Dover has the largest parts investment in the lift industry. The REMSTAR computerized parts system rivals what car manufacturers operate. When you need a replacement cylinder, seal, cable, control, or any other part for a Rotary lift, it ships fast. Parts availability is not a problem for 5-year-old Rotary lifts, 10-year-old lifts, or even 20-year-old lifts. That long-term parts support protects your investment.

Warranty with Labor Coverage

Rotary offers a 5-year structural warranty, 1-year warranty on operating functional parts, and — critically — a 1-year labor warranty. The labor warranty sets Rotary apart from most competitors, whose warranties are parts-only. If a covered component fails in the first year, Rotary covers the cost of the technician to replace it. For a commercial shop where downtime costs money, that labor warranty has real value.

Direct-Drive Reliability

The direct-drive hydraulic system means no chains, no chain adjustment, no chain replacement. Over a 10-year ownership period, the reduced maintenance on a Rotary direct-drive system compared to a chain-drive competitor can offset a meaningful portion of the initial price premium.

Resale Value

Rotary lifts hold their value better than any other brand. A used Rotary in good condition sells for a significant percentage of its original price. If you ever sell your shop or upgrade your equipment, a Rotary lift has real resale value. Budget brands depreciate faster because there is less demand for them on the secondary market.

Compared to Other Brands

Against Atlas, Rotary is the premium choice. Atlas gives you excellent value for the dollar. Rotary gives you American manufacturing, direct-drive technology, a labor warranty, and the largest support network in the industry. Both are good lifts — Rotary is the better lift if your budget allows it.

Against Challenger, the comparison is interesting. Both are Made in USA. Challenger competes aggressively on price while maintaining domestic manufacturing. Rotary has the edge in technology (Shockwave, Spotline, direct-drive) and the larger support network. Challenger often wins on price in the heavy-duty space.

Against BendPak, Rotary wins on Made in USA manufacturing, direct-drive technology, and the dealer/support network. BendPak is a strong brand with a loyal following, particularly in the home garage market. However, BendPak uses chain-over-roller drive systems on most models, while Rotary uses direct-drive — a fundamental technology difference that affects long-term maintenance costs and reliability.

Against imported brands (many Chinese-manufactured lifts sold under various brand names), Rotary represents a completely different tier. The price difference is significant, but so is the quality difference: American manufacturing, ALI Gold Certification with testing beyond 20,000 cycles, direct-drive hydraulic cylinders, the world’s largest parts infrastructure, a labor warranty, and the backing of a Fortune 500 company. Imported lifts may look similar in photographs, but the engineering, materials, testing, and support are not comparable.

The fundamental question for any shop owner is this: will the lift I buy today still be performing reliably, with parts available and a manufacturer standing behind it, in 15-20 years? With Rotary, the answer is an unequivocal yes. Dover Corporation will be here. VSG will be here. The Madison, Indiana factory will be here. The REMSTAR parts system will still stock every component for your lift. That certainty has value — significant value — for any business making a capital equipment investment.

1. Rotary SPOA10 — The Undisputed Champion

The SPOA10 is the world’s number one selling two-post lift. It has been for decades. When a dealership or professional shop needs a two-post lift and does not want to compromise on anything, they buy the SPOA10. The true asymmetric design, Double S column, direct-drive cylinders, hydraulic safety system, and Rotary’s parts/support infrastructure make this the lift that every other two-post is measured against.

Best for: Dealerships, professional independent shops, fleet maintenance, any operation where quality and long-term reliability matter more than initial purchase price.

2. Rotary SPO12 — The Tall Lift for Tall Vehicles

With the explosive growth in cargo vans (Mercedes Sprinter, Ford Transit, RAM ProMaster), shops need lifts that can handle tall, heavy commercial vehicles. The SPO12 at 12,000 lbs with a 13′ 8″ overall height provides the clearance and capacity that these vehicles demand. The 25-second full rise with Shockwave makes high-volume van service practical.

Best for: Fleet maintenance shops, van upfitters, commercial vehicle service centers, any shop servicing modern cargo vans regularly.

3. Rotary SM14 — The Four-Post Standard

The SM14 sets the standard for four-post lifts with its industry-best 78 3/4″ rise, single-piece non-welded runways, and Sentinel Lock System. Available in standard (182″ wheelbase) and extended (215″ wheelbase) configurations, the SM14 handles the full range of passenger vehicles and light trucks.

Full Specs Summary:

• Capacity: 14,000 lbs — ALI Gold Certified
• Rise: 78 3/4″
• Runway Width: 20″ single-piece, non-welded
• Overall Width: 10′ 11 3/4″
• Available lengths: Standard (20′ 10″), Extended (23′ 7″)
• Power: 2 HP, 208-230V single phase
• Warranty: 5yr structural / 1yr functional / 1yr labor

Best for: Dealerships, commercial shops needing four-post versatility, alignment shops (with alignment conversion kit), storage applications.

4. Rotary SM18 — The Heavy-Duty Workhorse

At 18,000 lbs with a 230″ maximum wheelbase, the SM18 handles light and medium-duty commercial vehicles that exceed the SM14’s capacity. The alignment conversion option transforms it into a heavy-duty alignment platform. The 22″ runways provide extra width for larger commercial tires.

Best for: Commercial vehicle shops, fleet maintenance facilities, municipalities, any operation servicing vehicles above 14,000 lbs GVW.

5. Rotary SPO16 — The Versatile Heavy-Duty Two-Post

The SPO16 at 16,000 lbs fills the gap between the SPO12 and SPO20. With 3-stage AV (All-Vehicle) arms and the low-clearance height option, it handles Classes 1-4 in a single platform. The Shockwave option cuts cycle times in half.

Best for: Multi-purpose shops that service both passenger vehicles and medium-duty trucks, fleet operations with diverse vehicle mixes.

Rotary Lift and Electric Vehicles — Ready for the Future

The automotive industry’s transition to electric vehicles creates new challenges for lift equipment, and Rotary is at the forefront of addressing them. EVs are heavier than equivalent ICE vehicles due to battery packs, have lower ground clearance in many cases, and require precise lift point positioning to avoid battery pack damage.

Rotary lifts are well-prepared for EV service:

• Capacity: The SPOA10 at 10,000 lbs handles all current passenger EVs including heavy models like the Ford F-150 Lightning (6,500 lbs) and Rivian R1T (7,200 lbs). For the heaviest EVs like the Hummer EV (9,000+ lbs), the SPO12 at 12,000 lbs provides adequate margin.
• Low Pad Height: The SPOA10’s 4 3/4″ minimum pad height reaches the lift points on most EVs, which often sit low due to the floor-mounted battery pack.
• All-Vehicle Arms: The SPOA10-AV variant with All-Vehicle lift arms is specifically designed to handle the widest range of vehicles, including battery electric vehicles and exotics. The AV arms include adjustable truck adapters, round adapters, and adapter extensions that accommodate the unique lift point configurations found on EVs.
• Smooth Direct-Drive Operation: The direct-drive hydraulic system provides smooth, controlled lifting without the jerky motion that chain-drive systems can produce. This smooth operation is important for EVs where the battery pack is sensitive to impact and uneven forces.

Rotary’s engineering team actively works with EV manufacturers to ensure their lifts accommodate new vehicle designs. As the EV market grows, Rotary continues to update their adapter and arm systems to handle the latest vehicle platforms. When you invest in a Rotary lift today, you are investing in a platform that will adapt to the vehicles of tomorrow.

When Rotary Makes the Most Sense

• Dealerships: There is a reason 80%+ of U.S. car dealers use Rotary. The quality, warranty, and support meet the demands of high-volume dealership service.
• Fleet Operations: Government and corporate fleets often require Buy American compliance. Rotary checks that box while delivering the reliability fleet managers need.
• High-Volume Shops: If your lifts cycle dozens of times daily, the direct-drive reliability and Shockwave speed pay for themselves.
• Long-Term Investment: If you plan to own your shop for 15-20 years, Rotary’s long-term parts support and durability make it the lowest total cost of ownership.

Ceiling and Bay Requirements

The SPOA10 requires a minimum 12′ ceiling. The SPO12 needs 14′. The SM14 four-post requires only 7′ 6 1/2″ of column height. Check your bay dimensions against the specific model specs before ordering — Rotary provides minimum bay size requirements for every model.

Electrical Requirements

Most Rotary lifts run on 208-230V single-phase power. The SPOA10 draws 12-16 amps on a 20A circuit. Shockwave-equipped models use a separate 5 HP 110V motor. Ensure your shop has adequate electrical service before ordering.

Concrete Requirements

Two-post lifts require a minimum 4 1/4″ concrete slab at 3,000 PSI compressive strength. Check with your concrete contractor if you are unsure about your slab specifications. Installing a lift on inadequate concrete is dangerous and voids the warranty. If your slab does not meet the minimum requirement, reinforcement options include pouring a thicker pad in the lift location or using structural concrete repair products to achieve the required strength and thickness.

Installation Best Practices

Professional installation by a qualified lift installer is strongly recommended for all Rotary lifts. Key installation considerations include:

• Anchor bolt placement: Follow the factory template precisely. Anchor bolt spacing and torque specifications are critical for structural integrity.
• Column alignment: Both columns must be perfectly plumb. A misaligned column creates uneven forces that accelerate wear and can compromise safety.
• Electrical connection: Use a licensed electrician for power unit connection. Verify voltage, phase, and amperage match the lift specifications before energizing.
• Overhead clearance verification: Check clearance with the lift at full extension, accounting for the tallest vehicle you plan to service on the lift.
• Post-installation testing: Cycle the lift multiple times without a vehicle to verify proper hydraulic operation, lock engagement, and safety system function before placing any vehicle on the lift.

Rotary Lift Maintenance

Rotary’s direct-drive design minimizes maintenance requirements, but regular inspections extend lift life and ensure safe operation:

• Monthly: Visual inspection of hydraulic hoses, fittings, and cylinders for leaks. Check arm restraints and lock mechanisms. Inspect lift pads and adapters for wear.
• Quarterly: Check hydraulic fluid level. Inspect slide blocks for wear. Lubricate arm pivots per the owner’s manual. Inspect equalization cables (on models that use them).
• Annually: Professional inspection by a qualified lift inspector. ALI recommends annual inspections for all commercial lifts. This is the most important maintenance item — do not skip it.

Car Dealerships

Over 80% of car dealerships in the United States use Rotary lifts, and there are specific reasons for this dominance. Dealerships require equipment that meets manufacturer facility standards, provides consistent performance across dozens of daily service cycles, supports warranty and service documentation requirements, and maintains a professional appearance in high-traffic service departments.

For a typical dealership service bay, we recommend:

• Standard bays: SPOA10 or SPOA10-AV — the 10,000 lb capacity handles the full range of passenger vehicles, and the AV variant accommodates the growing EV fleet.
• Heavy-duty bays: SPO12 or SPO16 — for dealerships that service 3/4-ton and 1-ton trucks (Silverado 2500/3500, F-250/350, RAM 2500/3500).
• Quick service bays: SPOA7 with Shockwave — fast cycle times for oil changes, tire rotations, and routine inspections.
• Alignment bays: SM14 with alignment conversion kit — the four-post platform provides stable alignment work with the option to add rolling jacks for suspension unloading.
• Premium dealerships: SmartLift SL210 inground — flush-floor aesthetics with full service capability for BMW, Mercedes, Porsche, and other luxury brands.

Independent Repair Shops

Independent shops need lifts that handle the widest possible vehicle mix while providing long-term reliability. The SPOA10 remains the go-to choice, but independent shops should consider the SPOA10-AV variant for maximum vehicle compatibility. The All-Vehicle arms handle everything from lowered sports cars to lifted trucks to electric vehicles without requiring arm changes or special adapters.

For independent shops on a budget, our Forward Lift i10 delivers Dover/VSG quality at a lower price point. If your budget allows the Rotary premium, the SPOA10 provides the most comprehensive package of technology, warranty, and long-term support available.

Fleet Maintenance Facilities

Fleet facilities require equipment that handles diverse vehicle types, withstands heavy daily use, and meets compliance requirements. Rotary serves fleet operations with:

• Light/medium vehicle fleet: SPO12 or SPO16 two-post lifts for vehicles up to 16,000 lbs.
• Heavy vehicle fleet: MCHM14 or MCHM19 mobile column lifts for trucks and buses.
• Mixed fleet: Combination of SPOA10 (passenger vehicles), SPO16 (medium trucks), and MCHM19 (heavy vehicles).
• Government/military: All Rotary products are Made in USA, meeting Buy American requirements. ALI Gold Certification provides the documented safety compliance that government agencies require.

Home Garages and Enthusiasts

For the serious home garage builder who wants the best, Rotary’s SPOA10 is the gold standard. It requires a minimum 12-foot ceiling, 4 1/4″ concrete at 3,000 PSI, and a 20-amp 208-230V circuit. If these requirements are met, the SPOA10 provides professional-grade lifting in a home environment. The direct-drive system’s low maintenance requirements are particularly appealing for home use, where the owner wants to install the lift and use it for years without worrying about chain adjustments.

Understanding Rotary’s Total Cost of Ownership Advantage

Rotary lifts carry a higher initial purchase price than many competitors. This is an honest reality that we do not try to hide. However, the total cost of ownership over a 15-20 year period tells a different story:
